Occupancy Motion Sensor in-Wall Switch with 0-10V Dimming, SWX-103-D-WH, PIR Detection, Manual On (Vacancy Mode), 120/277V, 800W/1200W, 1-Pole, No Neutral Required, White, Made in USA

The SENSORWORX family of wall switch occupancy/vacancy sensors provides a simple yet cost effective lighting control solution for many retrofit applications. Designed with contractors in mind, the SENSORWORX 0-10V dimming wall switch sensor is significantly shallower than typical dimmers and sensors, resulting in less crowed wall boxes. Additionally, versatile wiring enables usage with or without a neutral and allows reversal of line and load connections. SENSORWORX products utilize the latest passive infrared technology and digital signal processing techniques to provide unmatched motion detection performance. These units are also available with an integrated microphone to provide overlapping passive acoustic occupancy detection for rooms with obstructions or where occupant motion is limited. For dimming adjustment, intuitive raise and lower buttons are present in a addition to an on/off button.

• Passive Infrared (PIR) Detection: Provides small motion detection up to 20 feet and large motion detection greater than 36 feet. Best choice for small rooms or enclosed spaces. A PIR only sensor is sufficient for spaces where line of site is maintained and occupants are periodically moving.
• Intuitive Wiring: No Neutral wire required, unit is safe to power over ground connection only. No Minimum Load required. Interchangeable Line and Load wires, impossible to wire backwards.
• Unique Bat-Wing Lens Design: Wall to wall passive infrared (PIR) motion detection via a bat-wing shaped lens that enhances peripheral motion detection. Rugged vandal resistant lens prevents accidental damage.
• Versatile Installation: Requiring less than 1" of mounting depth in a single gang wallbox, this unit is shallower than other in-wall devices.
• Dimming Control: This sensor also enables manual dimming control of 0-10V lighting, providing precise control over lighting levels. Dimming feature also enables Partial On operating mode. Note, controlled lighting must have 0-10VDC dimming wires.
• Additional Features: Sensor comes preset to Manual On (Vacancy) operating mode. Device allows user to easily modify its configuration settings like time delay, sequence of operation (e.g. Auto On, Manual On, etc), and dimming trim levels. Settings are changed via a push-button sequence that can be done safely in seconds without removing the cover plate.
• Quality and Compliance: Proudly made in the USA, 5-year warranty. UL Listed, RoHS Compliant, BAA Compliant, TAA Compliant, Meets ASHRAE 90.1, IECC, and Title 24.
