ERX-10 Multifunctional Timer Relay(220VAC 24VAC-DC)

relayGeneralERX-10 time relay is specifically designed for controlling the time and incoming data and can be used in industry, residential,factory facilities.Device's Adjusting Buttons:Function button (Fn): This button determines the functions. Please choose the desired function from the table.Max Time button (tm): This button determines the maximum time demand. It has a maximum of 10 time value.Time Multiply Button(Xn): It allows you to reach at intermediate values by multiplying maximum values.It has 10 step multiplying value between 0.1-1.0Usage of Device and Working Principle:Please connect the device according to the diagram.Please define the function and time settings before energising the device.Time=Maximum time(tm) x Time Scale Factor (Xn)Example: Lets say If the device is energised, it is desired that the relay becomes activated for 15 mins. and then should not be deactivated until de-energised.[ 15 min= Adjust the fn button to 2.Then adjust the MAX button (tm) to 30 min [g] and the time scale factor button to 30m.30 min] x0.5] After the desired function and time is adjusted, the device can be energised accordingly.Function Button(Fn)-1- ON DelayAfter the device is powered on, the delay starts, the M Led flashes during timing, and the relay is output after the delay ends, relay Led is on and the M Led is on.Re-execution requires power-off reset.-2- OFF DelayAfter the device is powered on, Relay immediately output, relay Led on, delay starts, the M Led flashes during timing, and the relay is stop output after the delay ends, relay Led off and the M Led is on. Re-execution requires power-off reset.-3- Control ON DelayAfter the device is powered on, when the T signal is turned on, the delay starts, the M Led flashes, and the relay outputs after the end, relay Led on and the M Led is on.If the T signal is turned off during the delay process, the delay will be s
